1-Bed Mountain Ranch House Plan with Angled 3-Car Garage - 1738 Sq Ft
Heated S.F.
1,738
Beds
1 - 3
Baths
1.5 - 2.5
Stories
1
Cars
3
Floor Plan

Plan 135330GRA

Main Level
slide image 0
2nd Floor
slide image 1

Plan 135330GRA

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • This mountain ranch house plan offers you 1,783 square feet of heated living space with 1-3 beds, 1.5-2.5 baths and a 1,159 square foot 3-car garage.
  • Architectural Designs' primary focus is to make the process of finding and buying house plans more convenient for those interested in constructing new homes - single family and multi-family ones - as well as garages, pool houses and even sheds and backyard offices.
  • Our website offers a vast collection of home designs, encompassing various architectural styles, sizes, and features, which can be customized to meet specific needs and preferences
  • We curate and add to our design portfolio every day as we work with hundreds of residential building designers and architects to bring you the most diverse and best house plans available.
  • We can modify any house plan you see on our site. Learn more about modifications.
What's Included
  • Elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
View Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

1,738 sq. ft.

1st Floor

1,738 sq. ft.

Basement Unfinished

1,738 sq. ft.

Porch, Front

220 sq. ft.

Deck

364 sq. ft.

Covered Patio

369 sq. ft.

Beds/Baths

Bedrooms

1, 2, or 3

Full bathrooms

1 or 2

Half bathrooms

1

Foundation Type

Standard Foundations

Walkout

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

58' 0"

Depth

54' 0"

Max Ridge Height

18' 11"

Garage

Type

Attached

Area

1159 sq. ft.

Count

3 Cars

Entry Location

Front, Courtyard

Ceiling Heights

Lower Level

9'

First Floor

9'

Roof Details

Primary Pitch

8 on 12

Secondary Pitch

3 on 12

Framing Type

Truss

Architectural Style

Mountain

Ranch

Special Features

Angled Garage

Bedrooms - Split

Flex Room

Formal Dining

Game/Rec Room

Master Suite - 1st Floor

Mudroom

Wet Bar

Square Footage Breakdown

Total Heated Area

1,738 sq. ft.

1st Floor

1,738 sq. ft.

Basement Unfinished

1,738 sq. ft.

Porch, Front

220 sq. ft.

Deck

364 sq. ft.

Covered Patio

369 sq. ft.
