Plan 8170LB
15-Foot Wide House Plan with Rear Access Garage - 1966 Sq Ft
Heated S.F.
1,966
Beds
4
Baths
3
Stories
2
Cars
1
Floor Plan

Plan 8170LB

Main Level
slide image 0
2nd Floor
slide image 1

Plan 8170LB

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • This 15-foot wide house plan gives you 4 beds, 3 baths and 1,966 square feet of heated living space and a rear access 280 square foot 1-car garage.
  • Architectural Designs primary focus is to make the process of finding and buying house plans more convenient for those interested in constructing new homes - single family and multi-family ones - as well as garages, pool houses and even sheds and backyard offices.
  • Our website offers a vast collection of home designs, encompassing various architectural styles, sizes, and features, which can be customized to meet specific needs and preferences.
  • We curate and add to our design portfolio every day as we work with hundreds of residential building designers and architects to bring you the most diverse and best house plans available.
  • We can modify any house plan you see on our site. Learn more about modifications.
What's Included
  • Elevations (All 4 Sides: Front, Left, Rear, Right)
  • Dimensioned Foundation Plan
  • Dimensioned Floor Plan(s)
  • Upper Level Framing Plan & Notes (if applicable)
  • Building Sections
  • Roof Framing Plan/Truss Layout
  • Typical Notes & Details
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

1,966 sq. ft.

1st Floor

873 sq. ft.

2nd Floor

1,093 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

15' 0"

Depth

80' 0"

Max Ridge Height

29' 0"

Garage

Type

Attached

Area

280 sq. ft.

Count

1 Cars

Entry Location

Rear

Ceiling Heights

First Floor

9'

Second Floor

8'

Architectural Style

Bungalow

Cottage

Craftsman

Northwest

Special Features

Den

Laundry - Main Level

Laundry - Upstairs

Master Suite - 2nd Floor

Square Footage Breakdown

Total Heated Area

1,966 sq. ft.

1st Floor

873 sq. ft.

2nd Floor

1,093 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

15' 0"

Depth

80' 0"

Max Ridge Height

29' 0"

Garage

Type

Attached

Area

280 sq. ft.

Count

1 Cars

Entry Location

Rear

Ceiling Heights

First Floor

9'

Second Floor

8'

Architectural Style

Bungalow

Cottage

Craftsman

Northwest

Special Features

Den

Laundry - Main Level

Laundry - Upstairs

Master Suite - 2nd Floor
