2-Story Barndominium with Drive-thru Garage - 1690 Sq Ft - 623152DJ

Plan 623152DJ

2-Story Barndominium with Drive-thru Garage - 1690 Sq Ft

Heated S.F.

1,690

Beds

Baths

2.5

Stories

Cars

Floor Plan

Main Level

2nd Floor

Plan Details

The rectangular footprint of this two-story Barndominium house plan designed with 2x6 exterior walls keeps budget in mind, while the modern interior features an open floor plan filled with natural lighting.
A fireplace surrounded by built-ins anchors the left wall of the great room and dining area, crowned by tall ceilings offering a glimpse into the upstairs loft.
The island kitchen enjoys a hidden pantry to maximize storage and a nearby mudroom provides an exterior door to the side.
The double garage is attached to the rear and features overhead doors on either side to allow you to drive through the garage.
Two bedrooms and a laundry room can be found upstairs. The largest bedroom is reserved for the homeowner and includes a 4-fixture bathroom.

What's Included

Cover Sheet: Shows the front elevation and typical notes and requirements.
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
Roof Plan
Typical Wall Section
Typical Stair Section (if applicable)
Cabinets Elevations (if applicable)

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
