Plan 680148VR
2400 Square Foot Detached Garage with Lift-Friendly RV Bay
Heated S.F.
0
Beds
Baths
0
Stories
1
Cars
5- 6
Floor Plan

Plan 680148VR

Main Level
slide image 0

Plan 680148VR

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • This 60' by 40' detached garage plan gives you 2,400 square feet of parking space set behind three garage doors
  • Two bays have 16' by 10' overhead doors and can park two cars each tandem-style.
  • The third bay has a 12' by 12' overhead door and is suitable for an RV or two cars parked tandem-style.
  • Related Plan: Get an alternate version with garage plan 68428VR (1,920 sq. ft.).

What's Included

  • Floor Plans: House plan drawings indicating dimensions for construction
  • Roof Plan: Drawings indicating roof slopes and unique conditions
  • Exterior Elevations: Drawings showing appearance and the types of materials used for the exterior finish and trim
  • Building Sections: Drawings cut through important locations in the structure
  • Construction Details: Drawings showing specific construction of building elements at a large scale
  • Kitchen and bath elevations (excluded on garage plans)
  • Electrical Plans: Basic electrical layout (suggested locations of fixtures, switches and outlets)
  • Foundation Plan: Dimensioned drawings describing specific foundation conditions for the structure
  • Building license: A single-use license for construction at one location only

What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

0 sq. ft.

Beds/Baths

Bedrooms

0

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

60' 0"

Depth

40' 0"

Max Ridge Height

25' 1"

Garage

Area

2400 sq. ft.

Count

5 or 6 Cars

Entry Location

Front

Ceiling Heights

First Floor

13' 6"

Roof Details

Primary Pitch

6 on 12

Framing Type

Truss

Architectural Style

Traditional

Special Features

Workshop

Square Footage Breakdown

Total Heated Area

0 sq. ft.

Beds/Baths

Bedrooms

0

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

60' 0"

Depth

40' 0"

Max Ridge Height

25' 1"

Garage

Area

2400 sq. ft.

Count

5 or 6 Cars

Entry Location

Front

Ceiling Heights

First Floor

13' 6"

Roof Details

Primary Pitch

6 on 12

Framing Type

Truss

Architectural Style

Traditional

Special Features

Workshop
