Plan 580039DFT
3-Bed Contemporary Farmhouse Ranch House Plan with Open Layout and Sun Deck
Heated S.F.
1,827
Beds
3
Baths
2
Stories
1
Cars
2
Floor Plan

Plan 580039DFT

Main Level
slide image 0

Plan 580039DFT

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • A low-pitched roof caps this 3-bedroom Contemporary Farmhouse Ranch house plan with deep-overhanging eaves providing additional shade.
  • The seamless flow between the kitchen, dining area, and great room helps to bring family and friends together, and a 12'6" by 11' sun deck offers a great spot to grill.
  • A flush eating bar at the kitchen island is ideal for snacks or casual meals, and the corner pantry increases storage for dry / canned foods.
  • The master bedroom offers rear-facing views and the attached bath and walk-in closet serve as an additional barrier between the master and secondary bedrooms.
  • Bedrooms 2 and 3 are just off the entry, separated by the hall bath. A built-in desk nearby serves as the perfect homework station.
What's Included

  • Cover Sheet: General Notes and code criteria
  • Foundation Plan: Concrete layouts including footings, slabs and stem walls, dimensions, floor joist layout, plumbing fixture locations and construction notes and details
  • Floor Plan(s): Dimensions, wall framing, room sizes, door and window location and sizes, plumbing fixtures, kitchen layout with cabinetry location and construction notes and details
  • Roof Plan: Bird's eye view and general layout, roof pitches, eave sizes, special ceiling heights, trey ceilings located and construction notes and details
  • Section View(s): A cut or cuts through the home showing wall plate heights, stair sections, special construction sections including footings and crawl space or slab details
  • Exterior Elevations: Shows 2-D exterior views of all 4 sides of home locating and showing roof lines, roof pitches, material callouts, window locations, vents, trim style and plate heights
  • Electrical Plans: General layout of smoke detectors, carbon monoxide detectors, exhaust fans, lights, switches, outlets and GFI outlets

What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

1,827 sq. ft.

1st Floor

1,827 sq. ft.

Porch, Front

62 sq. ft.

Covered Patio

125 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Crawl, Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

50' 0"

Depth

59' 6"

Garage

Type

Attached

Area

627 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

10'

Roof Details

Primary Pitch

5 on 12

Framing Type

Stick And Truss

Architectural Style

Country

Modern Farmhouse

New American

Northwest

Ranch

Special Features

Bedrooms - Split

Breakfast Nook

Home Office

Laundry - Main Level

Master Suite - 1st Floor

Workshop

Square Footage Breakdown

Total Heated Area

1,827 sq. ft.

1st Floor

1,827 sq. ft.

Porch, Front

62 sq. ft.

Covered Patio

125 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Crawl, Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

50' 0"

Depth

59' 6"

Garage

Type

Attached

Area

627 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

10'

Roof Details

Primary Pitch

5 on 12

Framing Type

Stick And Truss

Architectural Style

Country

Modern Farmhouse

New American

Northwest

Ranch

Special Features

Bedrooms - Split

Breakfast Nook

Home Office

Laundry - Main Level

Master Suite - 1st Floor

Workshop
