3-Bed Cottage Ranch Home Plan with L-Shaped Porch - 1701 Sq Ft

Heated S.F.

1,701

Beds

Baths

Stories

Cars

Build Gallery

See and hear from existing customers with real photos, videos, and reviews.

House Plan 62568DJ Comes to Life in Alaska

Photos

House Plan 62568DJ Comes to Life in Iowa

Photos

House Plan 62568DJ comes to life in Tennessee

Photos

Floor Plan

Main Level

Plan Details

This 3 bed modern cottage ranch has an attractive gable over the garage and a shed dormer over the L-shaped porch. The unique exterior an eclectic use of materials, not too unlike the Craftsman style, with elegant modern elements - standing seam metal over the porch, shed dormer and garage roofs - combining to give it an overall uncluttered look and feel.
Inside, an open floor plan greets you with the great room blending into the dining room and kitchen. A fireplace on the left is flanked by built ins.
The bedrooms are split maximizing your privacy with the master bedroom featuring a 10' tray ceiling. Across the home two bedrooms share a hall bath.
The kitchen has a deep walk-in pantry hidden by cabinet-faced doors.
Related Plans: Get an alternate version with house plans 62725DJ and 62732DJ.

What's Included

Cover Sheet: Shows the front elevation and typical notes and requirements.
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
Roof Plan
Typical Wall Section
Typical Stair Section (if applicable)
Cabinets Elevations (if applicable)

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
