Plan 420110WNT

Exclusive

3-Bed Craftsman with Covered Porches and 2-Car Side Garage - 1328 Sq Ft
Heated S.F.
1,328
Beds
3
Baths
2
Stories
1
Cars
2
Floor Plan

Plan 420110WNT

Main Level
slide image 0

Plan 420110WNT

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • This 3 bed, 2 bath Craftsman-style house plan gives you 1,328 square feet of heated living with a front porch (105 square foot greeting) and a rear porch (220 square feet) accessible both from the kitchen/dining area and the 2-car garage (440 square feet).
  • The center of the home is open front to back with the great room with tray ceiling just inside the entry.
  • A split bedroom layout has the master suite alone on the left with a walk-in closet and a 5-fixture bath and Beds 2 and 3 across the home sharing a bath.
  • Laundry is tucked away by the family entry.
  • NOTE: Please allow 3 to 5 business days for delivery.
What's Included
  • Foundation Plan - Footing sizes, slab thickness, floor framing sizes/layout, etc.
  • Floor Plan(s) - Detailed dimensions, window/door details, plumbing fixture type/locations, etc. for each level of the home.
  • Electrical Layout Plan - Locations of electrical panels, lights, switches, outlets, etc.
  • Roof Plan - Roof framing sizes/layout, roof pitch, attic venting, overhangs, roof finish materials, etc.
  • Exterior Elevations - Views of the front, rear, and sides of home detailing exterior finish work.
  • Building Cross Section - View that depicts a vertical slice through the building.
  • Details and notes - Dissected drawings of foundation/footings, typical wall section, floor framing, door framing, window framing, roof framing, roof venting, insulation information etc.
View Sample Plan
What's Not Included
  • Architectural or Engineering Stamp
  • Mechanical Drawings (Drawings for HVAC duct sizes/locations) Typically provided by your HVAC subcontractor
  • Plumbing Drawings (Drawings for plumbing pipe sizes/locations) Typically provided by your Plumbing Subcontractor
  • Energy Calculations (Property specific energy efficiency calculations) Typically provided by local Energy Consultant
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

1,328 sq. ft.

1st Floor

1,328 sq. ft.

Porch, Front

105 sq. ft.

Porch, Rear

220 sq. ft.

Porch, Combined

325 sq. ft.

Covered Patio

325 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Monolithic Slab, Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

45' 0"

Depth

57' 6"

Max Ridge Height

20' 10"

Garage

Type

Attached

Area

440 sq. ft.

Count

2 Cars

Entry Location

Side, Rear

Ceiling Heights

First Floor

9'

Room

Ceiling Type

Height

Living Room

Tray

10' 0''

Master Bedroom

Tray

10' 0''

Front Porch

Vaulted

9' 0''

Roof Details

Primary Pitch

9 on 12

Secondary Pitch

9 on 12

Framing Type

Stick And Truss

Architectural Style

Cottage

Country

Craftsman

New American

Ranch

Special Features

Bedrooms - Split

Laundry - Main Level

Master Suite - 1st Floor

Mudroom

Plan Collections

Exclusive

Square Footage Breakdown

Total Heated Area

1,328 sq. ft.

1st Floor

1,328 sq. ft.

Porch, Front

105 sq. ft.

Porch, Rear

220 sq. ft.

Porch, Combined

325 sq. ft.

Covered Patio

325 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Monolithic Slab, Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

45' 0"

Depth

57' 6"

Max Ridge Height

20' 10"

Garage

Type

Attached

Area

440 sq. ft.

Count

2 Cars

Entry Location

Side, Rear

Ceiling Heights

First Floor

9'

Room

Ceiling Type

Height

Living Room

Tray

10' 0''

Master Bedroom

Tray

10' 0''

Front Porch

Vaulted

9' 0''

Roof Details

Primary Pitch

9 on 12

Secondary Pitch

9 on 12

Framing Type

Stick And Truss

Architectural Style

Cottage

Country

Craftsman

New American

Ranch

Special Features

Bedrooms - Split

Laundry - Main Level

Master Suite - 1st Floor

Mudroom

Plan Collections

Exclusive
