Plan 135262GRA

3-Bedroom Barndominium House Plan with 1-Bed In-Law Suite - 4413 Sq Ft

Heated S.F.

4,413

Beds

4

Baths

4.5

Stories

2

Cars

1

Floor Plan

Main Level

floor plan image Main Level

2nd Floor

floor plan image 2nd Floor

Plan Details

The main part of this barndominium house plan gives you 3 bedrooms, 2 baths and 2,249 square feet of heated living space plus a 840 square foot L-shaped proch. On the other side of the 799 square foot garage you'll find a 1-bed, 1,388 square foot apartment with a 490 square foot porch on the side.
Each side of the home has a great room (the one on the left is vaulted) and its own kitchen and laundry facilities.
At the back of the main house, the office can be accessed from the master suite (it can also be accessed from the garage). The apartment also has a home office.
Stairs along the side of the garage take you to a 779 square foot vaulted loft with storage.
We can modify any house plan you see on our site. Learn more about modifications.

What's Included

Elevations
Fully Dimensioned Floor Plans
Roof Plan & Sections
Foundation plan
General Notes
Suggested Electrical Layout

View Sample Plan

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

Modify This Plan

Need to make changes? We will get you a free price quote within 1 to 3 business days.

Square Footage Breakdown

Total Heated Area

4,413 sq. ft.

1st Floor

2,249 sq. ft.

2nd Floor

779 sq. ft.

Apartment

1,153 sq. ft.

Porch, Front

840 sq. ft.

Side Porch

490 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

4

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

102' 6"

Depth

70' 0"

Max Ridge Height

22' 5"

Garage

Type

Attached

Area

799 sq. ft.

Count

1 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

4 on 12

Framing Type

Truss

Architectural Style

Special Features

Bedrooms - Clustered

Laundry - Main Level

Master Suite - 1st Floor

Two Story Great Room

Wrap Around Porch

Plan Collections

Attached Apartments

Multi-Generational

Square Footage Breakdown

Total Heated Area

4,413 sq. ft.

1st Floor

2,249 sq. ft.

2nd Floor

779 sq. ft.

Apartment

1,153 sq. ft.

Porch, Front

840 sq. ft.

Side Porch

490 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

4

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

102' 6"

Depth

70' 0"

Max Ridge Height

22' 5"

Garage

Type

Attached

Area

799 sq. ft.

Count

1 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

4 on 12

Framing Type

Truss

Architectural Style

Special Features

Bedrooms - Clustered

Laundry - Main Level

Master Suite - 1st Floor

Two Story Great Room

Wrap Around Porch

Plan Collections

Attached Apartments

Multi-Generational
