Name: Plan 82286KA: 3100 Square Foot Coastal Mediterranean Home Plan with Central Lanai
SKU: 82286KA
Price: 3500.0 USD
Availability: InStock

Plan 82286KA

3100 Square Foot Coastal Mediterranean Home Plan with Central Lanai

Heated S.F.

3,100

Beds

2 - 3

Baths

2.5

Stories

Cars

Floor Plan

Main Level

Plan Details

The 2-car garage that extends from this Coastal Mediterranean home plan creates a welcoming motor court, while the interior surrounds a central lanai for outdoor living at its finest.
A study, or lounge, and formal dining room flank the foyer. The heart of the home can be found towards the rear and flows into a family room with a tray ceiling and fireplace.
The master bedroom occupies the left side of the design with a deluxe ensuite featuring a freestanding tub in front of an oversized shower.
A Jack-and-Jill bathroom sits in between the two secondary bedrooms that can be transformed into a home theatre and gym if preferred.
The 2-car garage includes a man door to the side yard and a mudroom provides the perfect drop zone just inside.

What's Included

Foundation Plan: Complete with dimensions, dimensioned plumbing, referenced details, General Notes and Schedules.
Elevations: Minimal four completed elevations with dimensions, notes and material call outs. Also exterior details where applicable.
Floor Plan(s): Complete with dimensions and notes of all elements. On our high-end plans we provide architectural and structural floor plans, as typical part of our sets to avoid clatter and for easy construction.
Roof Plan: Complete with roof pitches overhangs and notes for special condition also dimensions on any special condition as per plan.
Building Sections: Where applicable, building sections are included. The quantity of these drawings is determined by the plan set complexity.
Details: Interior and Exterior details as require per plan. Common details are: Applicable Cornice (Eve) and Special Details designed directly from the plan (not typical details that are reused for every plan produced). We do this to improve the accuracy and integrity that should be expected from quality set of plans.
Interior Elevations: Some sets include interior Kitchen, Bathrooms and other significant detailed plan specific areas.
Roof Framing Plan: Engineered truss layout from a local truss company. All hangers, connectors and or special details are shown. Since local codes and conditions very, this plan is for reference only.
Floor Framing Plan: Only were needed. Engineered floor truss layout from a local truss company. All hangers, connectors and or special details are shown. Since local codes and conditions very, this plan is for reference only.
Building Sections: Complete with layout, light fixtures, outlets, legend and notes.
Electrical Plan: Complete with layout, Light fixtures, Outlets and legend.
Lintel Plan: Provided with block concrete masonry unit plans only. Lintel sizes and details for all exterior openings. Since local codes and conditions very, this plan is for reference only.
Structural Details: Including wall sections and all framing details needed per plans. Since local codes and conditions very, this plan is for reference only.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
