Plan 710146BTZ
5-Bed Country Home Plan with Wraparound Porch and 3 Fireplaces
Heated S.F.
5,466
Beds
5
Baths
5.5+
Stories
2
Cars
3
Floor Plan

Plan 710146BTZ

Main Level
slide image 0
2nd Floor
slide image 1

Plan 710146BTZ

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • Three gables and a beautiful front porch that wraps around the right side and extends to the back guest suite greet you to this 5-bed country home plan with a side-entry garage with a gambrel roofline.
  • There are three fireplaces inside. One is located in the grand room with and the other in the cozy hearth room adjoining the kitchen and the third is in the master suite.
  • The master suite name featuring a personal lounging room with a fireplace, a lavish master bath with private dressing area, and direct access to the exercise room.
  • Guests will enjoy the privacy of their accommodations, with a private bath and French doors that lead to the wrap-around porch.
  • A covered side entrance, butler's pantry and art niches are added extras that help make this home special.
What's Included
  • Elevations -  at 1/4" or 3/16" and the side and rear elevations at 1/8" scale. The elevations show and note the exterior finished materials of the house.
  • Foundation - every plan is available with a walkout style basement (three masonry walls and one wood framed rear wall with windows and doors).  The basement plans are a 1/4" or 3/16" scale layout of unfinished spaces showing only the necessary 2 x 6 wood framed load bearing walls.  These plans are completed with dimensions, door/window sizes.  Crawlspace and/or slab on grade foundations are available for some plans.
  • Floor plan - each plan consists of 1/4" or 3/16" scale layouts showing the location of 2 x 4 walls, doors, windows, plumbing fixtures, cabinetry, stairs and decorative ceilings. These plans are complete with dimensions, notes, door/window sizes and a schematic electrical layout.
  • Building sections - Take vertical cuts throughout the house and the stairs showing floor, ceiling and roof height information.
  • Floor framing - if included it shows each floor joist indicating the size, spacing and length.  All beams are sized and labeled.  Each framing plan sheet includes any framing details that are needed (tray details, connections details, etc. All framing is designed using conventional 2 x 10 floor joist or wood I-joist, depending on the span conditions of each home. FRAMING PLANS ARE NOT AVAILABLE for all home so please follow up with us for availability.
  • Ceiling framing - if included, it shows each ceiling joist indicating the size, spacing and length.  All beams are sized and labeled.  All of the joists are counted and coordinated with the material list.  FRAMING PLANS ARE NOT AVAILABLE for all home so please follow up with us for availability.
  • Roof framing - if included, shows each rafter, valley, hip and ridge indicating size, spacing and length.  All beams are sized and labeled.  All of the joists are counted and coordinated with the material list.  FRAMING PLANS ARE NOT AVAILABLE for all home so please follow up with us for availability.
  • Details sheets - shows foundation details, typical wall section and other framing details.  Also included are miscellaneous interior trim and fireplace details that can be used to customize the home.
What's Not Included
  • Architectural or Engineering Stamp
  • Site Plan
  • Mechanical Drawings (location of heating and air equipment and duct work)
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  • Energy calculations
  • Windows and Doors Schedules

Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

5,466 sq. ft.

1st Floor

2,732 sq. ft.

2nd Floor

2,734 sq. ft.

Basement Unfinished

2,732 sq. ft.

Beds/Baths

Bedrooms

5

Full bathrooms

5

Half bathrooms

2

Foundation Type

Standard Foundations

Crawl, Slab, Walkout

Exterior Walls

Exterior Walls

2x4

Dimensions

Width

85' 0"

Depth

85' 6"

Max Ridge Height

39' 0"

Garage

Type

Attached

Area

764 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Primary Pitch

10 on 12

Framing Type

Stick

Architectural Style

Country

Southern

Traditional

Special Features

Butler Walk-in Pantry

Laundry - Main Level

Master Suite - 2nd Floor

Master Suite - Sitting Area

Multiple Stairs

Wrap Around Porch

Plan Collections

Luxury

Photo Gallery
