Plan 5796HA
Brickwork Cottage
Heated S.F.
1,161
Beds
3
Baths
2
Stories
1
Floor Plan

Plan 5796HA

Main Level
slide image 0

Plan 5796HA

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • Brickwork and feature window add elegance to this home plan perfect for a narrow lot.
  • Living room enjoys a vaulted ceiling, fireplace and opens to kitchen.
  • U-shaped kitchen offers a breakfast area with bay window, snack bar and built-in pantry.
What's Included
  • Front Cover Sheet
  • Detailed Floor Plans
  • Foundation Plan
  • Roof Plan
  • Exterior Elevations
  • Interior Elevations
  • Cross Section
  • Mechanical – Shows location of furnace
  • Electrical – Shows location of outlets, switches and fixtures
  • Plumbing – Shows location of fixtures
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

1,161 sq. ft.

1st Floor

1,161 sq. ft.

Basement Unfinished

1,149 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

30' 0"

Depth

44' 0"

Max Ridge Height

20' 0"

Ceiling Heights

First Floor

8'

Roof Details

Primary Pitch

6 on 12

Secondary Pitch

10 on 12

Framing Type

Truss

Architectural Style

Cottage

Special Features

Bedrooms - Clustered

Master Suite - 1st Floor

Square Footage Breakdown

Total Heated Area

1,161 sq. ft.

1st Floor

1,161 sq. ft.

Basement Unfinished

1,149 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

30' 0"

Depth

44' 0"

Max Ridge Height

20' 0"

Ceiling Heights

First Floor

8'

Roof Details

Primary Pitch

6 on 12

Secondary Pitch

10 on 12

Framing Type

Truss

Architectural Style

Cottage

Special Features

Bedrooms - Clustered

Master Suite - 1st Floor
