Plan 8182LB
Carriage House in the Woods
Heated S.F.
624
Beds
1
Baths
1
Stories
2
Cars
2
Floor Plan

Plan 8182LB

Main Level
slide image 0
2nd Floor
slide image 1

Plan 8182LB

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • This carriage house plan is can be used as a guest cottage, a vacation escape, home studio or a workshop.
  • A shed dormer gives the upper floor lots of light and great headroom for such a small package.
  • The main floor has room for 2 cars. Stairs in the back take you to the living floor where you find the living room open to the wet bar. A bed and bath complete the home.
  • The primary roof pitch is 12:12; the shed dormer has a roof pitch of 5:12.
  • Related Plan: Simplify the upstairs with house plan 8172LB (414 sq. ft.).
What's Included
  • Elevations (All 4 Sides: Front, Left, Rear, Right)
  • Dimensioned Foundation Plan
  • Dimensioned Floor Plan(s)
  • Upper Level Framing Plan & Notes (if applicable)
  • Building Sections
  • Roof Framing Plan/Truss Layout
  • Typical Notes & Details
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

624 sq. ft.

2nd Floor

624 sq. ft.

Beds/Baths

Bedrooms

1

Full bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

24' 0"

Depth

26' 0"

Max Ridge Height

25' 0"

Garage

Type

Detached

Area

577 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Second Floor

8'

Roof Details

Primary Pitch

12 on 12

Secondary Pitch

5 on 12

Architectural Style

Carriage

Country

Craftsman

Rustic

Special Features

Laundry - Upstairs

Master Suite - 2nd Floor

Wet Bar

Workshop

Plan Collections

ADU
