Plan 86114BW

Coastal Contemporary House Plan with 4 Beds and 5 Baths Including the Pool Bath

Heated S.F.

3,290

Beds

Baths

Stories

Cars

Floor Plan

Main Level

Plan Details

This 1-story coastal contemporary house plan gives you 3,290 square feet of heated and cooled living space with four bedrooms all with their own bathrooms. There's also a fifth bathroom - the pool bath - a must when you have a 1,758 square foot pool deck.
The house plan is designed with a slab foundation and concrete block exterior walls, a flat cement tile roof and a stucco finish.
Inside, amenities include a welcoming great room with a 12'8" tray ceiling, an island kitchen (12' ceiling) with large hidden pantry, a dining room (12'8" coffered ceiling), a study (12'8" coffered ceiling) and a dedicated laundry room.
The master bedroom suite has 2 walk-in closets, dual sinks, a walk-in shower and a free-standing tub.
The covered lanai includes an outdoor kitchen and an outdoor fireplace.

What's Included

Elevations - Drawn at 1/8″ to 1/4″ = 1’0″ scale and includes:

Material Labels
Floor-To-Floor Heights
Roof Slope Indicators

Floor Plans - Drawn at 1/8″ to 1/4″ = 1’0″ scale and includes:

Door and Window Sizes
Completely Dimensioned Floor Plan
Room Labels and Interior Room Size

Electrical Layouts

Building Section Markers
Electrical Outlets, Fixtures and Switching

Foundation Plan - Drawn at 1/8″ to 1/4″ = 1’0″ scale and includes:

Floor and Deck Joist Sizes, Spacing and Direction
Electrical Locations

Roof Plan - Drawn to 1/8″ to 1/4″ = 1’0″ scale and includes:

All Beam and Header Heights and Locations
All Hips, Gables, Ridges and Valley
Building Section Markers

Building Sections - Drawn to 1/8″ to 1/4″ = 1’0″ scale and includes:

Floor Joist Size and Spacing
Floor-To-Floor Heights
Non-Typical Plate Heights Indicated

Typical Wall Sections - Drawn at 1/8″ to 1/4″ = 1’0″ scale and includes:

All Labels Indicating Wall Construction
Foundation Wall Thickness and Reinforcing
Insulation Type and Thickness

Miscellaneous Notes and Details

Miscellaneous General Notes
Stairway Details (if applicable)

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
