Plan 5982ND

Compact Southern Home Plan - 2783 Sq Ft - Architectural Designs

Heated S.F.

2,783

Beds

3 - 4

Baths

3

Stories

2

Cars

2

Floor Plan

Main Level

floor plan image Main Level

Bonus

floor plan image Bonus

Plan Details

A large, open living/dining/kitchen area is the heart of this compact three bedroom home.
The covered patio off the family room expands your living space to the outdoors.
Vaulted ceilings abound, making the space seem even larger.
Related Plans: Eliminate the upper floor with house plan 59507ND (2,029 sq. ft.). Get a larger version with house plan 59583ND (2,261 sq. ft.).

What's Included

Foundation Plan (1/4″ or 1/2″ = 1′)
Floor Plans (1/4″= 1′)
Set of Elevations (1/4″= 1′)
Miscellaneous Details (3/4″ = 1′)
An electrical diagram showing a bird's-eye view of rooms with lights, fans to switches

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

Modify This Plan

Need to make changes? We will get you a free price quote within 1 to 3 business days.

Square Footage Breakdown

Total Heated Area

2,783 sq. ft.

1st Floor

2,029 sq. ft.

2nd Floor

754 sq. ft.

Porch, Front

195 sq. ft.

Porch, Rear

206 sq. ft.

Beds/Baths

Bedrooms

3 or 4

Full bathrooms

3

Foundation Type

Standard Foundations

Basement, Crawl, Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

66' 4"

Depth

58' 7"

Max Ridge Height

28' 1"

Garage

Type

Attached

Area

526 sq. ft.

Count

2 Cars

Entry Location

Side

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

10 on 12

Framing Type

Stick

Architectural Style

Special Features

Bedrooms - Clustered

Laundry - Main Level

Master Suite - 1st Floor
