Name: Plan 64523SC: Exclusive 5-Bed New American House Plan with Finished Lower Level - 5067 Sq Ft
SKU: 64523SC
Price: 2150.0 USD
Availability: InStock

Plan 64523SC

Exclusive

Exclusive 5-Bed New American House Plan with Finished Lower Level - 5067 Sq Ft

Heated S.F.

5,067

Beds

Baths

3.5

Stories

Cars

Floor Plan

Main Level

Lower Level

Plan Details

A covered courtyard on the front of this exclusive, New American Modern Farmhouse house plan welcomes guests and guides you into the entryway.
Wood beams enhance the vaulted ceiling above the living room, which offers a seamless flow into the kitchen, as well as views onto the rear covered patio.
Family and friends will gather around the kitchen island when entertaining and enjoy meals in the adjoining dining room. Other notable features in the kitchen include a wine fridge, double ovens, large range, and nearby coffee bar and walk-in pantry.
The master bedroom occupies the left side of the home and the master closet boasts a dresser island and access to the laundry room. Across the home, discover bedroom 2 and a home office.
The fun continues downstairs where you'll find a large rec / game room with a wet bar, three bedrooms, and plenty of storage space.

What's Included

Cover Sheet - project statistics, including square footages, 3D images (typically), general notes and drawings sheet index.
Foundation/basement plan - showing room/wall layout, beams, posts and joist direction, and often electrical outlets, switches and light locations.
Main Level Plan - floor plan rooms and walls dimensioned, window and door sizes noted, plumbing, millwork locations and other general notes.
Upper Level Plan (if needed) - same information as Main Level.
Roof Plan - layout with pitch markers, dimensions and notes.
Main Level Electrical Plan - electrical outlets, switches and light locations shown.
Upper Level Electrical Plan (if needed) - electrical outlets, switches and light locations shown.
Exterior Elevations - Elevations of the Front and Right side with notes, dimensions and material designations.
Exterior Elevations - Elevations of the Back and Left side with notes, dimensions and material designations.
Sections and details - One or more building sections to show vertical relationships and construction plate heights, details as needed.
Interior Elevations and Details - mostly millwork, fireplace and other items that need additional explanation, details as needed.

View Sample Plan

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
