Plan 23377JD
Great Indoor and Outdoor Spaces
Heated S.F.
2,045
Beds
3
Baths
2
Stories
2
Cars
2
Floor Plan

Plan 23377JD

Basement
slide image 0
Main Level
slide image 1
2nd Floor
slide image 2

Plan 23377JD

1-800-854-7852

1-262-521-4596

Basement
floor plan image Basement
Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • This is a very unique 2 bedroom house plan offering you great indoor and outdoor spaces for entertaining.
  • The covered porch extends around two sides including the large outdoor living room defined by three sets of triple columns.
  • The great room lies at the heart of the home and features a 2-story vaulted ceiling.
  • From the second floor you have views on two sides of the great room below but your privacy is assured by sturdy walls in both bedrooms.
  • A bridge walk helps with the views below and both bedrooms enjoy access to the upper deck.
  • The lower level gives you ample room for your vehicles and it includes a full bath and room for the mechanicals.
  • Related Plan: Get a 3 bedroom version with house plan 23603JD.
  • NOTE: Additional fees apply when building in the State of Washington. Contact us for more information.
What's Included
  • Cover Sheet - The cover sheet includes the general notes and building code information, design standards and structural materials specifications required to construct your home.
  • Schedule Sheet - The schedule sheet includes the roof and foundation ventilation schedules, insulation and vapor barrier specifications, and exhaust fan ventilation schedule.
  • Detail Sheet - The detail sheet shows building components at large scale as required to explain construction of footings, foundation walls, concrete slabs, framed floors and walls, posts, beams, insulation, eaves, roofs, vents, stairs, skylights, and connections.
  • Foundation Plan Sheet - The foundation plan sheet shows the layout of the crawl space, walk-out basement or slab foundation. The foundation plan includes all necessary notes, dimensions, concrete walls, footing pads, posts, beams, bearing walls, crawlspace vents, footing schedule, steel reinforcing, and structural information. If you require a different foundation type, please contact us for modifications to your plan.
  • Floor Plan Sheet - Floor plans are horizontal cuts through each floor level of the home, usually at 5' above the floor. The floor plan shows the location of interior and exterior walls, doors, windows, stairs, closets, cabinets, flooring, appliances, plumbing fixtures, fireplaces, posts and beams. Floor plans also indicate vaulted, coffered, or box beam ceilings, cased openings and areas with ceiling soffits.
  • Roof Framing Plan Sheet - The roof framing plan shows the geometry of the hips, ridges, valleys, dormers, roof pitches, wall and plate heights, and overhangs. The plan also shows all individual roof framing members, trusses, rafters, beams, skylights, roof vents, gutters, downspouts, skylights, bearing walls under framing members, and point loads.
  • Elevation Sheet - Exterior elevations show all four sides of the house, describing the roofing, siding, and trim materials, doors, windows, roof pitches, skylights, gutters, chimneys, wall heights, finish grade and overall building height.
  • Building Section Sheet - Building sections are vertical cuts through the house from the roof to the foundation. The sections illustrate the construction sequence from bottom to top starting with excavation, proceeding up through the foundation, drainage, wall and floor framing, stair framing, roof framing, windows, doors, venting, and exterior and interior finishes. Wall plate heights for each floor are also delineated.
What's Not Included
  • Electrical Plan - handled by your subcontractor to match your individual needs
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

2,045 sq. ft.

1st Floor

1,205 sq. ft.

2nd Floor

840 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

56' 0"

Depth

48' 0"

Max Ridge Height

24' 0"

Garage

Type

Drive Under

Area

2190 sq. ft.

Count

2 Cars

Entry Location

Side

Ceiling Heights

First Floor

9'

Second Floor

9'

Roof Details

Primary Pitch

4 on 12

Framing Type

Stick and Truss

Architectural Style

Coastal

Craftsman

Northwest

Shingle

Vacation

Special Features

Laundry - Main Level

Master Suite - 1st Floor

Two Story Great Room

Wrap Around Porch

Plan Collections

Sloping Lot

Square Footage Breakdown

Total Heated Area

2,045 sq. ft.

1st Floor

1,205 sq. ft.

2nd Floor

840 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

56' 0"

Depth

48' 0"

Max Ridge Height

24' 0"

Garage

Type

Drive Under

Area

2190 sq. ft.

Count

2 Cars

Entry Location

Side

Ceiling Heights

First Floor

9'

Second Floor

9'

Roof Details

Primary Pitch

4 on 12

Framing Type

Stick and Truss

Architectural Style

Coastal

Craftsman

Northwest

Shingle

Vacation

Special Features

Laundry - Main Level

Master Suite - 1st Floor

Two Story Great Room

Wrap Around Porch

Plan Collections

Sloping Lot
