Plan 57167HA
Ideal Cottage For Leisure Living
Heated S.F.
496
Beds
1
Baths
1
Stories
1
Cars
2
Floor Plan

Plan 57167HA

Main Level
slide image 0

Plan 57167HA

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • The traditional front exterior and rear both enjoy shady prorches for relaxing evenings.
  • The living room with bayed dining area is open to a functional L-shaped kitchen with a convenient pantry.
  • A full bath, large walk-in closet and access to both rear porch and garage are the many features of the rear bedroom.
What's Included
  • Front Cover Sheet
  • Detailed Floor Plans
  • Foundation Plan
  • Roof Plan
  • Exterior Elevations
  • Interior Elevations
  • Cross Section
  • Mechanical – Shows location of furnace
  • Electrical – Shows location of outlets, switches and fixtures
  • Plumbing – Shows location of fixtures
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

496 sq. ft.

1st Floor

496 sq. ft.

Beds/Baths

Bedrooms

1

Full bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

39' 0"

Depth

33' 0"

Max Ridge Height

16' 8"

Garage

Area

502 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

8'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

4 on 12

Framing Type

Truss

Architectural Style

Carriage

Cottage

Special Features

Master Suite - 1st Floor

Plan Collections

ADU

Square Footage Breakdown

Total Heated Area

496 sq. ft.

1st Floor

496 sq. ft.

Beds/Baths

Bedrooms

1

Full bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

39' 0"

Depth

33' 0"

Max Ridge Height

16' 8"

Garage

Area

502 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

8'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

4 on 12

Framing Type

Truss

Architectural Style

Carriage

Cottage

Special Features

Master Suite - 1st Floor

Plan Collections

ADU
