Plan 66260WE
Lanai on Two Floors
Heated S.F.
4,256
Beds
4 - 5
Baths
4.5
Stories
2
Cars
3
Floor Plan

Plan 66260WE

Main Level
slide image 0
2nd Floor
slide image 1

Plan 66260WE

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • The quaint front porch with radial area and cupola above is perfect for that front porch swing!
  • Inside, this great room floor plan opens up. It is perfect for entertaining with a large gourmet kitchen and dining room.
  • Each room has its own special feature; most with the intricate ceiling details you will find, even on the covered lanai.
  • A fun cabana is incorporated in this design for those wanting to get out of the sun but still enjoy the outdoors.
  • Upstairs you will find another covered lanai, 3 guest rooms, a bonus room and loft with wet bar.
  • This design offers the opportunity to add an elevator in the center of the stairs.
What's Included
Elevations - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Material Labels
  • Floor-to-Floor Heights
  • Roof Slope Indicators
Floor Plans - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Door and Window Sizes
  • Completely Dimensioned Floor Plan
  • Room Labels and Interior Room Sizes
Electrical Layouts
  • Building Section Markers
  • All Electrical Outlets, Fixtures, and Switching
Foundation Plan - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Floor and Deck Joist Size and Spacing
  • Electrical Locations (if applicable)

Roof Design Plan - Drawn at 1/8″ to 1/4″ = 1′-0″scale, and Includes:
  • All Beam and Header Heights and Locations
  • All Hips, Gables, Ridges, and Valleys
  • Building Section Markers
Building Sections - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Floor Joist Size and Spacing
  • Floor-to-Floor Heights
  • Non-Typical Plate Heights Indicated
Typical Wall Sections - Drawn at 1/8″ to 1/2″ = 1′-0″ Scale, and Includes:
  • All Labels Indicating Wall Construction
  • Foundation Wall Thickness and Reinforcing
  • Insulation Type and Thickness
Miscellaneous Notes and Details
  • Miscellaneous General Notes
  • Stairway details (if applicable)
We do provide a slab plan, however, the structural foundation plan is to be provided by the structural engineer selected by your builder or yourself. This is done because our slab plan cannot anticipate the variations in soil, footings and other conditions per your specific site. We provide the design of the roof as well, however, the truss layouts need to be provided by a truss engineer or your lumber company. Your builder can provide these contacts for you.  Please keep in mind that these are additional expenses outside of the cost of the original plan that you purchase from us.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

4,256 sq. ft.

1st Floor

2,840 sq. ft.

2nd Floor

1,416 sq. ft.

Bonus

257 sq. ft.

Entry

341 sq. ft.

Balcony / Veranda

471 sq. ft.

Lanai

887 sq. ft.

Beds/Baths

Bedrooms

4 or 5

Full bathrooms

4

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

Block / CMU (main floor)

Optional Type(s)

2x6

Dimensions

Width

98' 4"

Depth

66' 4"

Max Ridge Height

30' 0"

Garage

Type

Attached

Area

832 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

First Floor

12'

Second Floor

11'

Roof Details

Primary Pitch

6 on 12

Framing Type

Truss

Architectural Style

Florida

Southern

Special Features

Bonus Room

Butler Walk-in Pantry

Elevator

Laundry - Main Level

Loft

Master Suite - 1st Floor

Wet Bar

Plan Collections

Luxury

Photo Gallery

Premium Collection

Square Footage Breakdown

Total Heated Area

4,256 sq. ft.

1st Floor

2,840 sq. ft.

2nd Floor

1,416 sq. ft.

Bonus

257 sq. ft.

Entry

341 sq. ft.

Balcony / Veranda

471 sq. ft.

Lanai

887 sq. ft.

Beds/Baths

Bedrooms

4 or 5

Full bathrooms

4

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

Block / CMU (main floor)

Optional Type(s)

2x6

Dimensions

Width

98' 4"

Depth

66' 4"

Max Ridge Height

30' 0"

Garage

Type

Attached

Area

832 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

First Floor

12'

Second Floor

11'

Roof Details

Primary Pitch

6 on 12

Framing Type

Truss

Architectural Style

Florida

Southern

Special Features

Bonus Room

Butler Walk-in Pantry

Elevator

Laundry - Main Level

Loft

Master Suite - 1st Floor

Wet Bar

Plan Collections

Luxury

Photo Gallery

Premium Collection
