Plan 54064LK

Modern Hill Country House Plan with 4 Bedrooms, Game Room, and 3-Car Garage

Name: Plan 54064LK: Modern Hill Country House Plan with 4 Bedrooms, Game Room, and 3-Car Garage
Brand: Architectural Designs
SKU: 54064LK
Price: 2103.75 USD
Availability: InStock

Heated S.F.

3,410

Beds

Baths

3.5

Stories

Cars

Floor Plan

Main Level

2nd Level

Plan Details

This 3,410 sq ft Modern Hill Country house plan offers 4 bedrooms, 3.5 baths, and an attached 3-car garage spanning 1045 sq ft.
A welcoming covered entry, framed by stone accents, leads into an inviting interior, hinting at the open-concept layout and 10' main level ceilings.
The expansive main living area flows seamlessly with open-concept kitchen, dining, and family spaces, enhanced by a walk-in pantry and a charming breakfast nook.
The private primary suite, located on the first floor, offers a tranquil retreat, separated from the secondary bedrooms for optimal privacy.
Enjoy dedicated entertainment in the upstairs game/rec room, complete with a wet bar perfect for hosting.
Expansive covered porches totaling 575 sq ft provide ample outdoor living space, featuring an outdoor kitchen for alfresco dining.

What's Included

FLOOR PLAN: Showing all dimensions, window & door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, window & door schedules and specifications
FOUNDATION PLAN: Dimensioned plan detailing the location and size of footings, slabs, brick shelves reinforcing steel, direction and size of ceiling joists, Laminate beam locations, specifications covering soil pressure, concrete strength, and requirements for the contractor to follow accepted practices.
ELECTRICAL PLAN: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches and outlets.
ELEVATIONS: The front, rear and side elevations of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, and locations of chimney, exterior vents, etc. and also includes any necessary details.
ROOF PLANS: Provides a bird's eye view of the roof's valleys, ridges and dormers, if applicable
BUILDING CROSS SECTION: Shows details of the house as though it were cut in slices from the roof to the foundation. The cross sections detail the construction of the home, insulation, flooring and roofing.
INTERIOR ELEVATIONS: Show's how the details of cabinets such as those found in the kitchen, bathroom and utility room, fireplaces and other special interior features.
NOTES AND DETAILS: Provides information for structural specifications, excavating and grading, masonry and concrete work, carpentry and wood specifications, thermal and moisture protection and specifications about drywall, tile, flooring, glazing, caulking and sealants.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
