Plan 135255GRA
Mountain Ranch House Plan with Spectacular Rear Views - 2489 Sq Ft
Heated S.F.
2,489
Beds
3
Baths
2.5
Stories
1
Cars
3
Floor Plan

Plan 135255GRA

Main Level
slide image 0
Lower Level
slide image 1

Plan 135255GRA

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Lower Level
floor plan image Lower Level
Plan Details
  • This ranch house plan is perfect for a lake or mountain setting with its spectacular views to the back and its walkout basement. The home gives you 3 beds, 2.5 baths and 2,489 square feet of heated living plus an additional bedroom and bath and 2,495 square feet of lower level expansion when finished.
  • Architectural Designs' primary focus is to make the process of finding and buying house plans more convenient for those interested in constructing new homes - single family and multi-family ones - as well as garages, pool houses and even sheds and backyard offices.
  • Our website offers a vast collection of home designs, encompassing various architectural styles, sizes, and features, which can be customized to meet specific needs and preferences.
  • We curate and add to our design portfolio every day as we work with hundreds of residential building designers and architects to bring you the most diverse and best house plans available.
  • We can modify any house plan you see on our site. Learn more about modifications.
What's Included
  • Elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
View Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

2,489 sq. ft.

1st Floor

2,489 sq. ft.

Basement Unfinished

2,495 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Half bathrooms

1

Foundation Type

Standard Foundations

Walkout

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

102' 11"

Depth

53' 5"

Max Ridge Height

22' 0"

Garage

Type

Attached

Area

1358 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

Lower Level

9'

First Floor

9'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

10 on 12

Framing Type

Truss

Architectural Style

Craftsman

Hill Country

Lake House

Mountain

Ranch

Special Features

Bedrooms - Clustered

Butler Walk-in Pantry

Home Office

Home Theater

Laundry - Main Level

Master Suite - 1st Floor

Two Story Great Room

Wet Bar

Workshop
