Plan 135207GRA
Multi-Generational Barndo-Style House Plan with Massive Connecting Garage Shop - 4314 Sq Ft
Heated S.F.
4,314
Beds
4
Baths
3.5+
Stories
2
Cars
2
Floor Plan

Plan 135207GRA

Main Level
slide image 0
2nd Floor
slide image 1

Plan 135207GRA

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • This barndominium house plan designed with standard framing (i.e. 2x6 exterior walls) gives you 1,455 square feet of garage and shop space which provides separation between two separate-but-connected independent units, giving you multi-generational living with all its benefits.
  • The heart of the main home on the left is open with a two-story ceiling above the living and dining rooms. The spacious kitchen makes entertaining easy, while a quiet den nearby provides a more secluded space to unwind.
  • The master bedroom is located on the main level and features a 5-fixture bathroom with a walk-in closet that connects to the laundry room.
  • Upstairs, bedrooms 2 and 3 are mirror images of each other, and a loft offers a communal space for the kids to enjoy.
  • The right side gives you single-floor living with an open concept living area complete with a corner kitchen and a bedroom with bath, walk-in closet and its own laundry room.
  • The garage lends plenty of space for a shop or storage with two 10' by 8' garage doors in front and a smaller 8' by 7' one in back.
  • This plan is designed with conventional wood framing - with 2x6 exterior walls. The exterior finish is spec'd for corrugated metal siding.
  • Related Plans: Remove the unit on the right with house plan 135047GRA, 135190GRA, 135158GRA (on a walkout basement), 135078GRA and 135184GRA.
What's Included
  • Elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
View Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

4,314 sq. ft.

1st Floor

3,179 sq. ft.

2nd Floor

1,135 sq. ft.

Porch, Combined

1,072 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Half bathrooms

2

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

99' 0"

Depth

69' 0"

Max Ridge Height

28' 8"

Garage

Type

Attached

Area

1455 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Second Floor

8'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

4 on 12

Framing Type

Truss

Architectural Style

Barndominium

Country

Mountain

New American

Rustic

Traditional

Special Features

Butler Walk-in Pantry

Den

In-Law Suite

Laundry Access from Master Suite

Laundry - Main Level

Loft

Master Suite - 1st Floor

Two Story Great Room

Workshop

Plan Collections

Multi-Generational

Square Footage Breakdown

Total Heated Area

4,314 sq. ft.

1st Floor

3,179 sq. ft.

2nd Floor

1,135 sq. ft.

Porch, Combined

1,072 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Half bathrooms

2

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

99' 0"

Depth

69' 0"

Max Ridge Height

28' 8"

Garage

Type

Attached

Area

1455 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Second Floor

8'

Roof Details

Primary Pitch

7 on 12

Secondary Pitch

4 on 12

Framing Type

Truss

Architectural Style

Barndominium

Country

Mountain

New American

Rustic

Traditional

Special Features

Butler Walk-in Pantry

Den

In-Law Suite

Laundry Access from Master Suite

Laundry - Main Level

Loft

Master Suite - 1st Floor

Two Story Great Room

Workshop

Plan Collections

Multi-Generational
