Plan 42272WM
One-Story Ranch House Plan with Split Bedrooms - 1452 Sq Ft
Heated S.F.
1,452
Beds
3
Baths
2
Stories
1
Cars
2
Floor Plan

Plan 42272WM

Main Level
slide image 0

Plan 42272WM

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • A split bedroom layout places the master suite away from the family bedrooms, allowing each side their privacy.
  • The generously-sized front porch has plenty of room for comfortable chairs.
  • A fireplace is the focal point of the living room that is open to the dining room and kitchen.
  • Related Plan: For a different exterior with a study, see house plan 42273WM.
What's Included
  • Front elevation and construction notes
  • Rear and side elevations
  • Floor plan including electrical, window and door sizes, floor joist span direction and ceiling type notes (9' ceiling, vault, etc.)
  • Second floor plan (if applicable) with the same details as the first level floor plan
  • Typical wall section
  • Typical foundation details
  • Roof plan showing roof pitches, ridges and valleys, noted as 2" x 8" rafter or optional roof trusses
  • Foundation plan
  • Full building section
View Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

1,452 sq. ft.

1st Floor

1,452 sq. ft.

Porch, Front

162 sq. ft.

Porch, Rear

203 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

63' 0"

Depth

48' 0"

Max Ridge Height

21' 0"

Garage

Type

Attached

Area

516 sq. ft.

Count

2 Cars

Entry Location

Side

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

9 on 12

Architectural Style

Ranch

Traditional

Special Features

Bedrooms - Split

Breakfast Nook

Laundry - Main Level

Master Suite - 1st Floor

Square Footage Breakdown

Total Heated Area

1,452 sq. ft.

1st Floor

1,452 sq. ft.

Porch, Front

162 sq. ft.

Porch, Rear

203 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

63' 0"

Depth

48' 0"

Max Ridge Height

21' 0"

Garage

Type

Attached

Area

516 sq. ft.

Count

2 Cars

Entry Location

Side

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

9 on 12

Architectural Style

Ranch

Traditional

Special Features

Bedrooms - Split

Breakfast Nook

Laundry - Main Level

Master Suite - 1st Floor
