Plan 666034RAF
Three Level Contemporary House Plan
Heated S.F.
5,816
Beds
5
Baths
5.5
Stories
2
Cars
2
Floor Plan

Plan 666034RAF

Main Level
slide image 0
2nd Floor
slide image 1
Lower Level
slide image 2

Plan 666034RAF

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Lower Level
floor plan image Lower Level
Plan Details
  • With six bedrooms and over 5,800 square feet of living space, this exciting Contemporary house plan is meant for a large family.
  • Designed for a lot that slopes to the front, the garage is on the ground level that opens up to a play room and the sixth bedroom that is away from all the other bedrooms.
  • Formal and informal living spaces are both spacious and open concept to give you beautiful sight lines.
  • The guest bedroom on this level has a walk-in closet and private bathroom.
  • Skylights line the top floor balcony hallway that ends in a lounge on one side and the master suite on the other side.
  • There's a laundry room on this floor as well as the ground level making it most convenient.
  • Homeowners get a private deck where they can relax with a cup of coffee before starting the day.
What's Included
  • Cover Sheet with plan info
  • General Notes - Note: codes will not include local state adopted amendments
  • Fully dimensions and detailed floor plans
  • Elevations
  • Building Cross Section
  • Roof Plan
  • Details
  • Window Schedule
  • Original Structural plan FOR REFERENCE ONLY
What's Not Included
  • Architectural or Engineering Stamp  - handled locally when required
  • Site plans - handled locally - handled locally when required
  • Mechanical Drawings - handled locally when required
  • Plumbing Drawings  - handled locally when required
  • Electrical Drawings  - handled locally when required
  • Energy Calculations  - handled locally when required
  • Foundation and Framing plans  - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

5,816 sq. ft.

Lower Level

1,316 sq. ft.

1st Floor

2,455 sq. ft.

2nd Floor

2,045 sq. ft.

Porch, Front

52 sq. ft.

Deck

163 sq. ft.

Covered Patio

151 sq. ft.

Beds/Baths

Bedrooms

5

Full bathrooms

5

Half bathrooms

1

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

44' 0"

Depth

70' 6"

Garage

Type

Attached

Area

481 sq. ft.

Count

2 Cars

Ceiling Heights

Lower Level

9'

First Floor

10'

Second Floor

9'

Architectural Style

Contemporary

Modern

Special Features

Butler Walk-in Pantry

In-Law Suite

Jack & Jill Bath

Laundry - Upstairs

Master Suite - 2nd Floor

Master Suite - Sitting Area

Playroom
