Plan 57105HA
Two Bedroom Cottage With Garage And Shop
Heated S.F.
801
Beds
2
Baths
1
Stories
1
Cars
2
Floor Plan

Plan 57105HA

Main Level
slide image 0

Plan 57105HA

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • A wrap-around porch, roof dormer and fancy stonework all contribute to a delightful and charming exterior.
  • The living room enjoys a separate entry, a stone fireplace, vaulted ceiling and lots of windows.
  • The well-equipped kitchen has a snack bar and dining area with bay which offers access to the rear patio.
  • An oversized two-car garage features a large vaulted room ideal for a shop, studio, hobby room or office with built-in cabinets and access to the porch.
What's Included
  • Front Cover Sheet
  • Detailed Floor Plans
  • Foundation Plan
  • Roof Plan
  • Exterior Elevations
  • Interior Elevations
  • Cross Section
  • Mechanical – Shows location of furnace
  • Electrical – Shows location of outlets, switches and fixtures
  • Plumbing – Shows location of fixtures
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

801 sq. ft.

1st Floor

801 sq. ft.

Workshop

190 sq. ft.

Beds/Baths

Bedrooms

2

Full bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

51' 0"

Depth

34' 0"

Max Ridge Height

19' 0"

Garage

Type

Attached

Area

537 sq. ft.

Count

2 Cars

Entry Location

Side

Ceiling Heights

First Floor

8'

Roof Details

Primary Pitch

9 on 12

Framing Type

Truss

Architectural Style

Country

Special Features

Home Office

Laundry - Main Level

Master Suite - 1st Floor

Wrap Around Porch
